Gigabyte G1.Sniper Z5 User Manual

- 28 -
Hardware Installation
11) F_USB30 (USB 3.0/2.0 Header)
TheheaderconformstoUSB3.0/2.0specicationandcanprovidetwoUSBports. For purchasing the optional
3.5" front panel that provides two USB 3.0/2.0 ports, please contact the local dealer.
Pin No. Denition Pin No. Denition
1 VBUS 11 D2+
2 SSRX1- 12 D2-
3 SSRX1+ 13 GND
4 GND 14 SSTX2+
5 SSTX1- 15 SSTX2-
6 SSTX1+ 16 GND
7 GND 17 SSRX2+
8 D1- 18 SSRX2-
9 D1+ 19 VBUS
10 NC 20 No Pin
12) F_USB1/F_USB2 (USB 2.0/1.1 Headers)
 TheheadersconformtoUSB2.0/1.1specication.EachUSBheadercanprovidetwoUSBportsviaan
optional USB bracket. For purchasing the optional USB bracket, please contact the local dealer.
• DonotplugtheIEEE1394bracket(2x5-pin)cableintotheUSB2.0/1.1header.
• Prior to installing the USB bracket, be sure to turn off your computer and unplug the power cord
from the power outlet to prevent damage to the USB bracket.
Pin No. Denition
1 Power(5V)
2 Power(5V)
3 USBDX-
4 USB DY-
5 USBDX+
6 USB DY+
7 GND
8 GND
9 No Pin
10 NC
DEBUG
PORT
G.QBOFM
10
9
2
1
F_USB30
F_U
B_ 
F_  F_ 

_
B
BS_
B
SB_
B
_S

S_
_
B
_U
_
B


 
S  
 
123
 
123
 
123
 
123
1
1
1
1
BSS
S
_S 
SSU
 
1 2 3  
 S3
BSSS
U
 
1 2 3

 
1 2 3 
 
1 2 3

 
1 2 3 
 __ 3
F_USB3F
1
20
1011

Gigabyte G1.Sniper Z5 Specifications

General

Form Factor	ATX
Chipset	Intel Z87
CPU Socket	LGA 1150
Memory Type	DDR3
Max Memory	32GB
Storage	6 x SATA 6Gb/s
LAN	Qualcomm Atheros Killer E2201
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
Memory Standard	DDR3 1600/1333 MHz
Expansion Slots	2 x PCI Express x16, 2 x PCI Express x1, 2 x PCI
Multi-GPU Support	AMD CrossFireX
USB Ports	6 x USB 2.0
Audio	Creative Sound Core 3D
BIOS	2 x 64 Mbit flash, UEFI AMI BIOS
