Gigabyte G1.Sniper Z5 User Manual

- 95 -
Appendix
6-2-3 ConguringMicrophoneRecording
Step 2:
ConnectyourmicrophonetotheMicinjack(pink)onthe
backpanelortheMicinjack(pink)onthefrontpanel.
Then configure the jack for microphone functionality.
Note: The microphone functions on the front panel and
back panel cannot be used at the same time.
Step 3:
Go to the Microphone screen. Do not mute the recording
volume, or you'll not be able to record the sound. To hear
the sound being recorded during the recording process,
do not mute the playback volume. It is recommended that
you set the volumes at a middle level.
Step 4:
To raise the recording and playback volume for the
microphone, click the Microphone Boost icon on
the right of the Recording Volume slider and set the
Microphone Boost level.
Step 1:
Switchto Windows desktop mode. The HD Audio
Manager icon will appear in the notification area.
Double-click the icon to access the HD Audio Manager.

Gigabyte G1.Sniper Z5 Specifications

General

Form Factor	ATX
Chipset	Intel Z87
CPU Socket	LGA 1150
Memory Type	DDR3
Max Memory	32GB
Storage	6 x SATA 6Gb/s
LAN	Qualcomm Atheros Killer E2201
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
Memory Standard	DDR3 1600/1333 MHz
Expansion Slots	2 x PCI Express x16, 2 x PCI Express x1, 2 x PCI
Multi-GPU Support	AMD CrossFireX
USB Ports	6 x USB 2.0
Audio	Creative Sound Core 3D
BIOS	2 x 64 Mbit flash, UEFI AMI BIOS
