GA-8I945GMF-RH Motherboard - 10 -
English
CPU Supports Intel
®
Pentium
®
D / Pentium
®
4 LGA775 CPU
(Note 1)
Supports 1066/800/533MHz FSB
L2 cache varies with CPU
Chipset Northbridge: Intel
®
945G Express chipset
Southbridge: Intel
®
ICH7
Supported on the Win 2000/XP operating systems
Memory 4 DDRII DIMM memory slots (supports up to 4GB memory)
(Note 2)
Supports dual channel DDRII 667
(Note 3)
/533/400 DIMM
Supports 1.8V DDR II DIMM
Slots 1 PCI Express x 16 slot
1 PCI Express x 1 slot
2 PCI slots
IDE Connections 1 IDE connection (UDMA 33/ATA 66/ATA 100), allows connection of 2 IDE
devices
Supported on the Win 2000/XP operating systems
FDD Connections 1 FDD connection, allows connection of 2 FDD devices
Onboard SATA3Gb/s 4 SATA 3Gb/s connections
Supported on the Win 2000/XP operating systems
Peripherals 1 parallel port supporting Normal/EPP/ECP mode
1 VGA port, onboard COMA/COMB connection
8 USB 2.0/1.1 ports (rear x 4, front x 4 via cable)
3 IEEE1394 ports (rear x 1, front x2 via cable)
1 front audio connector
1 PS/2 keyboard port
1 PS/2 mouse port
Onboard LAN Onboard Marvell 8053 chip (10/100/1000 Mbit)
1 RJ 45 port
Supported on the Win 2000/XP operating systems
(Note 1) For further CPU support information, please go to GIGABYTE's website.
(Note 2) Due to standard PC architecture, a certain amount of memory is reserved for system usage
and therefore the actual memory size is less than the stated amount.
For example, 4 GB of memory size will instead be shown as 3.xxGB memory during system
startup.
(Note 3) To use a DDRII 667 memory module on the motherboard, you must install an 800/1066MHz
FSBprocessor .
1-2 Feature Summary
