Gigabyte GA-EP45-DS3 User Manual

Hardware Installation- 11 -
USB  Integrated in the South Bridge
 Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal Connectors  1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x floppy disk drive connector
 1 x IDE connector
 6 x SATA 3Gb/s connectors
 1 x CPU fan header
 2 x system fan headers
 1 x power fan header
 1 x front panel header
 1 x front panel audio header
 1 x CD In connector
 1 x S/PDIF In header
 1 x S/PDIF Out header
 2 x USB 2.0/1.1 headers
 1 x IEEE 1394a header
 1 x parallel port header
 1 x serial port header
 1 x power LED header
 1 x chassis intrusion header
Back Panel  1 x PS/2 keyboard port
Connectors  1 x PS/2 mouse port
 1 x coaxial S/PDIF Out connector
 1 x optical S/PDIF Out connector
 8 x USB 2.0/1.1 ports
 2 x IEEE 1394a ports
 2 x RJ-45 ports
 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side
Speaker Out/Line In/Line Out/Microphone)
I/O Controller  iTE IT8718 chip
Hardware Monitor  System voltage detection
 CPU/System temperature detection
 CPU/System/Power fan speed detection
 CPU overheating warning
 CPU/System/Power fan fail warning
 CPU/System fan speed control
(Note 4)

Gigabyte GA-EP45-DS3 Specifications

General

Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	2
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	8
VGA (D-Sub) ports quantity	0
BIOS type	AWARD
BIOS memory size	64 Mbit
Audio chip	Realtek ALC889A
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Vista/XP
LAN controller	Realtek RTL8111C
Networking features	10/100/1000 Mbit
