1-2 Product Specifications
CPU  Support for an Intel
®
Core
TM
2 Extreme processor/
Intel
®
Core
TM
2 Quad processor/Intel
®
Core
TM
2 Duo processor/
Intel
®
Pentium
®
processor Extreme Edition/Intel
®
Pentium
®
D processor/
Intel
®
Pentium
®
4 processor Extreme Edition/Intel
®
Pentium
®
4 processor/
Intel
®
Celeron
®
processor in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)
 Support for Intel
®
Hyper-Threading Technology
 L2 cache varies with CPU
Front Side Bus  1600(O.C.)/1333/1066/800 MHz FSB
Chipset  North Bridge: Intel
®
P35 Express Chipset
 South Bridge: Intel
®
ICH9R / ICH9
Memory  4 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
(Note 1)
 Dual channel memory architecture
 Support for DDR2 1200(O.C.)/1066/800/667 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio  Realtek ALC889A codec
 High Definition Audio
 2/4/5.1/7.1-channel
 Support for S/PDIF In/Out
 Support for CD In
LAN  RTL 8111B chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot
 3 x PCI Express x1 slots
 3 x PCI slots
Storage Interface  South Bridge:
- 6 x SATA 3Gb/s connectors (SATAII0, SATAII1, SATAII2, SATAII3,
SATAII4, SATAII5) supporting up to 6 SATA 3Gb/s devices
- 4 x SATA 3Gb/s connectors (SATAII0, SATAII1, SATAII4, SATAII5)
supporting up to 4 SATA 3Gb/s devices
(Note 2)
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
 GIGABYTE SATA2 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATAII0, GSATAII1) supporting up to
2 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, and JBOD
 iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
Only for GA-P35-DS3R.
Only for GA-P35-DS3.
Only for GA-P35-S3.
"*" Only the GA-P35-DS3R/DS3 adopt All-Solid Capacitor design.

Gigabyte GA-P35-DS3 Specifications

General

Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Audio chip	Realtek ALC889A
Audio output channels	7.1 channels
Motherboard form factor	ATX

Weight and Dimensions

Depth	210 mm
Width	305 mm
