Gigabyte GA-P55A-UD6 User Manual

- 53 - BIOS Setup
2-6 Integrated Peripherals
eXtreme Hard Drive (Intel P55 Chipset)
Enables or disables the X.H.D function for the SATA controllers integrated in the Intel P55 Chipset. When
set to Enabled, the PCH SATA Control Mode item below will be set to RAID(XHD) automatically. For
details on using the GIGABYTE X.H.D utility, refer to Chaper 4, "eXtreme Hard Drive (X.H.D)." (Default:
Disabled)
PCH SATA Control Mode (Intel P55 Chipset)
Enables or disables RAID for the SATA controllers integrated in the Intel P55 Chipset or congures the
SATA controllers to AHCI mode.
IDE Disables RAID for the SATA controllers and congures the SATA controllers to IDE
mode. (Default)
RAID(XHD) Enables RAID for the SATA controllers.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Integrated Peripherals
eXtreme Hard Drive (XHD) [Disabled]
PCH SATA Control Mode [IDE]
SATA Port0-3 Native Mode [Enabled]
USB Controllers [Enabled]
USB Legacy Function [Enabled]
USB Storage Function [Enabled]
Turbo SATA3/USB3.0 [Auto]
Azalia Codec [Auto]
PCI Express x4/x1 Slot [Auto]
Onboard H/W 1394 [Enabled]
Onboard H/W LAN1 [Enabled]
Onboard H/W LAN2 [Enabled]
Green LAN [Disabled]

SMART LAN1 [Press Enter]

SMART LAN2 [Press Enter]
Onboard LAN1 Boot ROM [Disabled]
Onboard LAN2 Boot ROM [Disabled
Onboard USB 3.0 Controller [Enabled]
Onboard IDE Controller [Enabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Integrated Peripherals
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

eSATA Controller [Enabled]
eSATA Ctrl Mode [IDE]
GSATA Controller [Enabled]
GSATA Ctrl Mode [IDE]
 GSATARAIDConguration  [PressEnter]
Onboard Serial Port 1 [3F8/IRQ4]

Gigabyte GA-P55A-UD6 Specifications

General

Memory voltage	1.5 V
Number of memory slots	6
Maximum internal memory	16 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
USB 2.0 connectors	2
Power fan connector	Yes
Number of SATA connectors	8
AGP x8 slots	0
Special features	@BIOS Q-Flash Xpress BIOS Rescue Download Center Xpress Install Xpress Recovery2
Controller interface type	iTE IT8720
Controller 2nd interface type	ATA-133/100/66/33
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC889
Motherboard chipset	Intel® P55
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Win XP, Vista, 7
PCI Express x16 slots	3
RAID levels	0, 1, 10
Bundled software	Norton Internet Security
Networking features	10/100/1000 Mbit
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
