Gigabyte R272-Z30 User Manual

Motherboard Components - 46 -
Chapter 4 Motherboard Components
4-1 Motherboard Components
CPU
DIMM_P0_A1 DIMM_P0_A0
DIMM_P0_B0 DIMM_P0_B1 DIMM_P0_C0 DIMM_P0_C1
DIMM_P0_D0 DIMM_P0_D1
DIMM_P0_F0 DIMM_P0_F1
DIMM_P0_G0 DIMM_P0_G1 DIMM_P0_H0 DIMM_P0_H1 DIMM_P0_E0 DIMM_P0_E1
2
34
1
5
6
7
89
10
11
12
2015 16 17 18 19 21
22
23
24
25
26
26
27
28
29
30
31
32
14
13
Item Description
1 SlimLine SAS Connector (U2_0)
2 SlimLine SAS Connector (U2_1)
3 SlimLine SAS Connector (U2_2)
4 SlimLine SAS Connector (U2_3)
5 Front Panel USB 3.0 Connector
6 Front Panel Connector
7 HDD Back Plane Board Connector
8 M.2 Connector (PCIe3 x4, NGFF-2280)
9 M.2 Connector (PCIe3 x4, NGFF-2280)
