02_05
02_06
Alignment adjustment (02_05, 02_06)
The vehicle is fitted with a special strut «B» connecting the engine and the chassis
that allows changing the running angles in 15 positions. This can be done by operating
the ring nut on the lower part of the strut. Rotating the ring nut modifies the rear sus-
pension height. Follow the adjustment procedure shown in the figure. This adjustment
affects the road behaviour of the vehicle. A low position is recommended to improve
vehicle stability at high speeds. A high position is recommended to improve manoeu-
vrability at low speeds (for instance, on city streets).
USING THE VEHICLE WITH A SPRING PRELOADING UNSUITABLE FOR THE
WEIGHT OF THE RIDER OR ANY PASSENGER CAN REDUCE RUNNING COM-
FORT AND DRIVING PRECISION.
ADJUST SHOCK ABSORBERS AND POSITION WITH THE VEHICLE RESTING
ON THE CENTRE STAND. THE USE OF A GLOVE IS ADVISED TO AVOID RISK
OF ABRASION DURING THE OPERATION.
Anti-overturning sensor
The vehicle is equipped with a special safety device coming from high-performance
cars and motorbikes, with a vehicle tilting sensor that stops the engine and the fuel
pump in case of falls.
39
