Programming a new wash program 49
Code 429159
Rev. 15/0717
Alternatively, using the outputs activation table the user can also calculate the decimal number to enter via the
alphanumeric keypad by knowing the value associated with each output on the A6(I/O2) board as described in
the following table:
Example: To find the decimal number equivalent to the combination of dosings d7, d10 and d12, add up the
values associated with these dosings:
equivalent decimal number = 4+32+128=164
Thus, 164 is the number to be entered via the alphanumeric keypad to activate Outputs d7, d10 and d12 of the
A6(I/O2) board.
