Glow-worm Climapro2 RF Installation

0020094586_01-08/10-Glow-worm
- 9 -
INSTALLATION
Case n°2 - radio receiver in the control box unit
A
RT 24V T° extBUS
BUS
24 V
B
1
2
3
5
4

 
 
 
 
 
• Donotremovethelinkfromtheterminalblock(2)connecting
theroomthermostattothemainboard.
• Connect(AandB)theEBUScable(1)totheradioreceiver's
connector(5)andtotheEBUSterminalblockonthemain
board(3).Thereisnopolaritythatmustberespected.
Case n°3 - radio receiver outside the appliance
1
2
3

 
 
 
• Donotremovethelinkfromtheterminalblockforconnecting
themainboard’sroomthermostat.
• ConnecttheEBUScabletotheradioreceiverconnector
andtheEBUSand0Vconnectionintheelectricalcartridge.
Polarityisnotimportant.
 
 

Thepairingbetweentheroomthermostatanditsradioreceiver
requiresnoactiononyourpart.Itiscarriedoutinthefactory.
 

Pairingbetweentheexternaltemperatureprobeandtheradio
receiverispossible(seetheinstallationmanualfortheexternal
probe).
Theradioreceivercanbepairedwiththewirelessoutdoor
sensor(seetheoutdoorsensorinstallationmanual).
