19
User Manual V1.4-2022-08-30 05 Installation
5 Installation
5.1 Installation Requirements
Installation Environment Requirements
1. Do not install the equipment in a place near ammable, explosive, or corrosive materials.
2. Do not install the equipment in a place that is easy to touch, especially within children’s reach.
High temperature exists when the equipment is working. Do not touch the surface to avoid
burning.
3. Avoid the water pipes and cables buried in the wall when drilling holes.
4. Install the equipment in a sheltered place to avoid direct sunlight, rain, and snow. Build a
sunshade if it is needed.
5. Install the equipment in a well-ventilated place to ensure good dissipation. Also, the
installation space should be large enough for operations.
6. The equipment with a high ingress protection rating can be installed indoors or outdoors.
The temperature and humidity at the installation site should be within the appropriate range.
7. Install the equipment at a height that is convenient for operation and maintenance, electrical
connections, and checking indicators and labels.
8. The inverter shall be installed below the maximum operating elevation of 3000m.
9. Install the equipment away from high magnetic elds to avoid electromagnetic interference.
If there is any radio or wireless communication equipment below 30MHz near the equipment,
you have to:
• Add a multi-turn winding ferrite core at the DC input line or AC output line of the inverter,
or add a low-pass EMI lter.
• Install the inverter at least 30m far away from the wireless equipment.
≥300mm
≥300mm
≥500mm
≥200mm
≥200mm
Children No Touch
To Next Page
