Gorenje GV63214 User Manual

Please carefully read the installation instruction.
● Illustrations of cabinet dimensions and installation position of the dishwasher
Preparations should be made before moving the dishwasher to the installation place.
Choose a place near the sink to facilitate the installation of inlet and drain hoses
(see figure 1).
If dishwasher is installed at the corner of the cabinet, there should be somespace
(illustrated in figure 2) when the door is opened.
2
1
16
Minimum space when
the door is opened
【Figure2】
Cabinet dimensions
【Figure1】
Cabinet
Dishwasher
Door of
dishwasher
Minimum space of 50mm
1 The aesthetic wooden panel could be processed according to the Figure 3.
The aesthetic panel should
be processed in accordance
with the illustrated dimensions
【Figure3】
●
Aesthetic panel's dimensions and installation
Less than 5mm
between the top
of dishwasher and
cabinet and the
outer door aligned
to cabinet.
90 °
90 °
600 mm
820mm
100
580mm
80
Space between cabinet
bottom and floor
Electrical, drain and
water supply line
entrances
(Unit: mm)

Gorenje GV63214 Specifications

General

Door color	Not applicable
Tub material	Stainless steel
Appliance placement	Fully built-in
Control panel color	Black, Grey
Built-in water softener	Yes
Cycle time	170 min
Noise level	49 dB
Delay start (max)	24 h
Dishwashing programs	Eco, Quick
Number of place settings	14 place settings
Number of washing programs	6
Number of temperature settings	4
Drying class	A
Feet adjustment	600 mm
AC input voltage	230 V
Water consumption per cycle	12 L
Energy consumption per cycle	1.04 kWh
Package depth	635 mm
Package width	630 mm
Package height	889 mm

Weight and Dimensions

Depth	5570 mm
Width	598 mm
Height	818 mm
Installation compartment depth	580 mm
Installation compartment height	820 mm
