Graco Reactor A-25 Operation

Models
309812D 3
Models
Air Powered Reactors
A SERIES
A-XP SERIES
Part No. Series Model
Voltage
(phase)
Heater
Watts
(no hose)
Flow
lb/min
(kg/min)
at 75 cpm
Output per
Cycle (A + B)
gal. (liter)
Pressure
Ratio
Maximum Fluid
Working Pressure
psi (MPa, bar)
246037 B A-25 230V (1) 10,200 25 (11) .031 (0.117) 16:1 1920 (13, 130)
246750 B A-25 230V (3) 10,200 25 (11) .031 (0.117) 16:1 1920 (13, 130)
246751 B A-25 380V (3) 10,200 25 (11) .031 (0.117) 16:1 1920 (13, 130)
at 45 cpm
246038 B A-50 230V (1) 15,300 50 (22) 0.114 (0.431) 26:1 2000 (14, 140)
246754 B A-50 230V (3) 15,300 50 (22) 0.114 (0.431) 26:1 2000 (14, 140)
246755 B A-50 380V (3) 15,300 50 (22) 0.114 (0.431) 26:1 2000 (14, 140)
Part No. Series Model
Voltage
(phase)
Heater
Watts
(no hose)
Flow
gpm (lpm)
at 78 cpm
Output per
Cycle (A + B)
gal. (liter)
Pressure
Ratio
Maximum Fluid
Working Pressure
psi (MPa, bar)
246639 B A-XP2 230V (1) 10,200 1.5 (5.7) .0193 (.073) 25:1 3000 (20.7, 207)
246752 B A-XP2 230V (3) 10,200 1.5 (5.7) .0193 (.073) 25:1 3000 (20.7, 207)
246753 B A-XP2 380V (3) 10,200 1.5 (5.7) .0193 (.073) 25:1 3000 (20.7, 207)
248635 A A-XP2
2:1
230V (1) 10,200 2.3 (8.6) .0290 (.110) 17.1:1 2050 (14.1, 141)
248636 A A-XP2
2:1
230V (3) 10,200 2.3 (8.6) .0290 (.110) 17.1:1 2050 (14.1, 141)
248637 A A-XP2
2:1
380V (3) 10,200 2.3 (8.6) .0290 (.110) 17.1:1 2050 (14.1, 141)
