Graco XM Series Instructions

Component Identification
313292K 11
Component Identification
Key:
A Pump Assembly
B Fluid Control Assembly (see Fluid Control Assembly, page 12)
C Control Box
D User Interface Display (see User Interface Display, page 15)
E Air Controls (see Air Controls, page 13)
F Air Inlet Manifold Assembly
68 Air Line
69 Air Line
FIG. 1: Typical OEM Sprayer Components
WLE
A
B
C
F
E
D
68
69
