Models
313292K 9
Models
Use the following matrix to define the construction of the sprayer, based on the six characters of the Part Number.
For example, Part XMEA00 represents an XM Plural-Component OEM sprayer (XM); 5200 psi pump set with pump
filters (E); wall power supply that is not approved for hazardous areas (A).
NOTE: To order replacement parts, see the Parts section your XM Plural-Component Sprayer Repair-Parts manual.
The digits in the matrix do not correspond to the Ref. numbers in the Parts drawings and lists.
Lower Models and Corresponding Identification Codes
NOTE: See Accessories and Kits, page 25, for a list of available accessories and kits.
XM OEM sprayers are not approved for use in
hazardous locations.
First and Second
Digits
Third Digit Fourth Digit
Fifth and Sixth
Digits
System Choice
(See below for lower models) Control Power
Pump Set Pump Filters
Remote
Mix Manifold Control Box Always 00
XM
(OEM plural
component sprayer
without a frame)
A no pumps
A Wall Power Supply
B no pumps
D Alternator
E 5200 psi
F 5200 psi
G 6300 psi
H 6300 psi
Code System Pressure
Pump
Filters
A Lower
(see your lower manual)
B Lower
(see your lower manual)
E 5200 psi (35 MPa, 350 bar)
L250C4 L220C4
F 5200 psi (35 MPa, 350 bar)
L250C3 L220C3
G 6300 psi (49 MPa, 490 bar)
L180C4 L145C4
H 6300 psi (49 MPa, 490 bar)
L180C3 L145C3
