EN - 18
For Best Mowing Results
• Cut grass when it is dry.
• Keep mower blades sharp.
• Keep mower deck properly leveled.
• Do not set height of cut too low. For very
tall grass, mow twice.
• Do not travel too fast.
• Mow with the engine set at full throttle.
• When mulching, only remove 1/3 of grass
length per cutting. Do not cut more than
2.5
cm (1") at any one time.
• Discharge clippings into areas already cut.
• Vary cutting pattern with each mowing.
• Do not allow grass or debris to collect
inside of mower deck. Clean after each
use.
STOP THE ENGINE
1. Move steering levers to neutral position.
2. Engage parking brake.
3. Push PTO knob down to off position.
4. Set throttle to slow speed.
5. Turn ignition key to off position and
remove key from ignition.
MOVE UNIT MANUALLY
See Figure 26.
IMPORTANT: There is one transaxle bypass
lever on each side of unit. Ensure that both
levers are fully in front or rear position.
• To disengage the transaxles and move unit
with the engine off, place both bypass
levers in the rear position.
• To engage transaxles and operate unit
normally, place both bypass levers in the
front position.
TRANSPORT UNIT
1. Stop engine, set parking brake and
remove key from ignition.
2. Secure unit chassis to transport vehicle.
NOTICE: NEVER secure from rods or
linkages that could be damaged.
Your Gravely dealer can provide service and
adjustments to keep your unit operating at
peak efficiency.
Contact an authorized engine manufacturer’s
service center for engine service.
WARNING: AVOID INJURY.
Wait for all moving parts to
stop before leaving operator’s
position.
MAINTENANCE
WARNING: AVOID INJURY.
Read and understand the
Safety section before
proceeding.
Front Position
Rear Position
Figure 26
