Gravely 915262 User Manual

EN - 25
Models 915255, 915256, 915257
See Figure 33.
1. Tip seat forward.
2. Loosen the two wing knobs located at the
front of the seat plate.
3. Adjust seat to desired position.
4. Tighten wing knobs.
5. Return seat to operating position.
ADJUST STEERING LEVERS
Adjust Steering Lever Height
See Figure 34.
1. Remove hardware securing steering
lever to upper control arm.
2. Place steering lever in desired adjusting
hole.
• Use upper and middle holes for highest
lever position.
• Use middle and lower holes for lowest
lever position.
3. Reinstall hardware in upper control arm.
4. Align levers side to side. See Adjust
Steering Level Reach on page 26.
5. Fully tighten hardware.
Figure 32
Figure 33
Figure 34
1. Adjusting Hole
2. Mounting Hole
3. Steering Lever
4. Upper Control Arm
4
3
2
1
