Centralized Controller
24
Press the up or down buttons to adjust temperature. Each time pressing the
button will increase/decrease the temperature by 1. Holding down the button can
increase/decrease temperature continuously.
Pressing the button can display the “indoor temp” and “outdoor temp”.
(4) Fan speed setting
Press the fan speed button to set fan speed.
NOTE:
Unit defaults to low fan speed in drying mode. Fan speed cannot be set
in drying or floor heating mode.
(5) Swing setting
Pressing the button “Up&Down Swing” or “Left&Right Swing” can turn on or off
the swing function.
NOTE:
Swing types for indoor units of different series are not all the same.
(6) Malfunction View
When indoor unit fails to function well, the will turn red. then press the button
to view the information of malfunctions.
5.3.2 Advanced Control Parameters
Press Advance Button to enter the advance page.
Press icon buttons to turn on or off the corresponding function.
Fig.5.3 Advance Page
