Gree CE54-24/F(C) User Manual

E-Smart Zone Controller
4
1.2 Wiring Instructions
1.2.1 Wiring Ports
Port
print
G1
、
G2
F1
、
F2
L
、
N
Meaning
CAN
communication
port
【
Reserved
】
Power
port
1.2.2 Power Supply
（
1
）
The centralized controller shall use independent power supply.
（
2
）
The range of input voltage: 110
～
240VAC; Frequency range: 50/60Hz.
（
3
）
Maximum rated power:3W.
（
4
）
The supply cord of this control can be replaced only by the manufacturer or
his accredited service agent.
（
5
）
Select power cord according to the following table. Never use the power cord
that is not in compliance with instructions of this manual.
Cord type
Cord standard
Cord size (mm
2
)
Single-core soft conductive
unsheathed cord(60227 IEC
08)
IEC 60227-3 2007
1.5
1.2.3 Connection Method
There are three methods to connect centralized controller with the air conditioning
system:

Gree CE54-24/F(C) Specifications

General

Brand	Gree
Model	CE54-24/F(C)
Category	Controller
Language	English
