Energy-Recovery Ventilation
System Service Manual
4 DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS
Name Function
Acentric Motor Sub-Assy. 0DNHWKHDLUÀRZ
Heat Exchange core.
The important Sub-Assy that make the
fresh air and room air exchange energy.
4.1 Main parts introduce
Main parts dismantle and install
Name: Service door’s teardown
Fig. show
Discharge the two bolts on the
right of the Service door, and
then take down the buckle.
Bolt
Name: Electric Box’s teardown
Fig. show
