Energy-Recovery Ventilation
System Service Manual
QSPEVDU
3.2 Standard Features
1. Replacement and Ventilation Function
It introduces fresh air into room and discharges indoor airout of room to make you feel comfortable as in
the nature.
2. Energy-recovery Function
Internal heat exchanger makes the discharged air and introduced air for cooling and heating exchange.
Energy-recovery rate above 70% keeps heat preservation and ventilation realized.
3. Low-noise Design
Special low-noise ventilation fan is set.
4. Air Filtration and Purge Function
,QWHUQDODLU¿OWHUNHHSVWKHIUHVKDLULQWURGXFHGLQWRURRPSXUHDQGGXVWOHVV
5. 9DULRXV6HULHVDQG0XOWLSOH6SHFL¿FDWLRQV
There are various series to match with the buildings of various structures.
4 PRODUCT DATA
4.1 Product Data at Rated Condition
Model FHBQ-D3.5-K FHBQ-D5-K FHBQ-D8-K FHBQ-D10-K
Code EH01100010 EH01100020 EH01100030 EH01100040
$LUÀRZ9ROXPH H-M-L m
3
/h 360-260-210 500-380-300 800-600-480 1000-750-600
External Statics Pressure H-M-L Pa 100-80-60 100-80-60 110-85-65 110-85-65
Temperature
H[FKDQJHHI¿FLHQF\
H-M-L % 71-73-75 68-70-72 70-72-74 75-77-79
Enthalpy
exchange
HI¿FLHQF\
Heating H-M-L % 65-67-68 62-64-65 63-65-67 66-68-70
Enthalpy
exchange
HI¿FLHQF\
Cooling H-M-L % 61-63-65 57-59-61 60-62-64 62-64-65
Recommended
wiring
Quantity 3 3 3 3
Area mm
2
1.0 1.0 1.0 1.0
Power Supply
220~240V~1Ph-
50Hz
220~240V~1Ph-
50Hz
220~240V~1Ph-
50Hz
220~240V~1Ph-
50Hz
Power Input W 165 262 400 440
Sound Pressure level dB(A) 37 39 45 46
Outline Dimension (W X D X H) mm 800X879X306 800X879X306 832X1016X380 832X1016X380
Package Dimension (WX D X H) mm 1050X1165X315 1050X1165X315 1087X1320X400 1087X1320X400
Net. Weight kg 45 45 57 57
*URVVZHLJKW kg 53 53 66.5 66.5
/RDGLQJTXDQWLW\
*3 63 63 40 40
*3 147 147 85 59
40'HQ 168 168 104 67
Standard wired remote controller Z5N15 Z5N15 Z5N15 Z5N15
