INSTALLATION
ACCESSORIES (PRODUCTS MAY DIFFER FROM THE DIAGRAMS)
Before beginning to install, make sure to have close at hand all the tools you will need (listed below) and
that all accessories and hardware parts provided with your air conditioner (as shown) are all included.
Top mounting rail
Window foam gasket
Right
expandable
panel
Tools needed
A. Level
B. Gloves
C. Flat blade and Phillips screwdrivers
D. Utility knife
E. Drill with 3/32” bit or smaller
F. Safety glasses
G. Tape measure
Hardware (included)
H. Window-lock bracket
I. Foam adhesive sealer
J. #8 x 3/8” round head Phillips screws (6)
K. #8 x 3/4” slot head wood screws (3)
H
A
B
C
D
E
F
G
I K
J
Air
conditioner
Left
expandable
panel
To Next Page
