Gree FP-85WA/GHL-K User Manual

Enginnering Data
26
50Hz (with the return air box), 3+1-row pipes
Type
Item
Concealed
ceiling type
FP-34WA
HT/BHL-
K
FP-51WA
HT/BHL-
K
FP-68WA
HT/BHL-
K
FP-85WA
HT/BHL-
K
FP-102W
AHT/BHL
-K
FP-136W
AHT/BHL
-K
FP-170W
AHT/BHL
-K
FP-204W
AHT/BHL
-K
Performance
Airflow
Hi
m
3
/h
340
510
680
850
1020
1360
1700
2040
Mid
248
393
510
638
788
1095
1275
1575
Low
213
263
340
425
525
730
850
1050
Cooling
capacity
Hi
W
2300
3600
4350
5400
6700
8100
10350
11000
Heating
capacity
Hi
W
2100
3350
4000
4600
5350
7000
8300
8950
Flow rate
m
3
/h
0.446
0.697
0.808
0.98
1.171
1.45
1.747
1.964
Water resistance
kPa
5.83
13.50
19.86
30.81
51.67
17.20
25.24
29.34
Noise
30Pa
40
42
44
46
47
48
50
52
External static
pressure
Pa
30pa
Coil
Type
Copper, high-efficiency louvered fins
Pressure
≤1.6MPa
Motor
Type
Class B, capacitor start
Quantity
/
1
2
Power supply
220-240V
～
50Hz
Protection class
IP20
Input power
30Pa
W
43
59
70
84
105
151
174
206
Power lines
mm
2
0.5×3
Protection class
I
Fan
Type
Front-forward multi-vane low-noise centrifugal fan
Quantity
/
1
2
3
4
Connection pipe
Inlet water
Rc3/4(female thread)
Outlet water
Rc3/4(female thread)
Condensate
R23/4(female thread)
Weight
Without return air
box
kg
14.4
17.2
19.2
20.5
23.2
34.2
37.5
37.5
Thermostat (optional)
Mechanical
Z54352A1
Digit
WK-110PA0
Deluxe digit
WK-010PA-K-K
1.5.2 Temperature at Nominal Conditions
Item
Water Side
Air Side
Entering water
temperature (
℃
)
Leaving water
temperature (
℃
)
DB Temperature
(
℃
)
WB Temperature (
℃
)
Cooling
7
45
12
27
19.5
Heating
60
-
21
-
1.5.3 Operation Range
Item
Water Side
Air Side
Leaving water temperature (
℃
)
进出水温差（℃）
Environment DB Temperature (
℃
)
Cooling
>5
2.5
～
6
16
～
40
Heating
<80
2.5
～
6
10
～
35
Note: when conditions are out of the range, please contact GREE.
