Technical Information
Service Manual
6. Function and Control
6.1 Remote Controller Introduction
Buttons on Remote Controller
Introduction for Icons on Display Screen
Introduction for Buttons on Remote Controller
T-ON T-OFF button
I FEEL button
/
ON/OFF button
MODE button
+/- button
QUIET button
SWING button
WiFi button
TEMP button
TURBO button
SLEEP button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
FAN button
button
ClOCK button
LIGHT button
/
Send signal
Turbo mode
8
heating function
Set temperature
Set time
X-FAN function
TIMER ON /TIMER OFF
Child lock
Up & down swing
Left & right swing
Set fan speed
Light
Temp. display type
:Set temp.
:Outdoor ambient temp.
:Indoor ambient temp.
Sleep mode
Clock
Heat mode
Fan mode
Dry mode
Cool mode
Auto mode
Operation mode
I feel
Healthy mode
Scavenging functions
Quiet
ON/OFF button
1
Press this button to turn on the unit. Press this button again to turn off the unit.
2
- button
Press this button to decrease set temperature. Holding it down above 2 seconds rapidly decreases set temperature. In AUTO
mode, set temperature is not adjustable.
Press this button to increase set temperature. Holding it down above 2 seconds rapidly increases set temperature. In AUTO
mode, set temperature is not adjustable.
Note:
This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model
doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status.
+ button

15
4
3
13
6
12
11
8
7
10
9
2
1
5
14
WiFi
