Gree GEH09AA-K6DNA1F User Manual

3
Technical Information
Service Manual
Parameter Unit Value
Model GEH12AA-K6DNA1A GEH09AA-K6DNA1F
Product Code CV010002900/CV010002901 CV010002700/CV010002701
Power
Supply
Rated Voltage V
～
220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) W 3520(800~4400) 2700(700~3400)
Heating Capacity(Min~Max) W 3800(1100~4400) 2900(600~3500)
Cooling Power Input(Min~Max) W 1000(160~1500) 720(170~1300)
Heating Power Input(Min~Max) W 960(165~1500) 730(130~1350)
Cooling Current Input A 4.48 3.5
Heating Current Input A 4.30 3.6
Rated Input W 1500 1350
Rated Current A 6.72 6.0
Air Flow Volume(SH/H/HM/M/LM/L/SL) m
3
/h 600/520/480/440/400/360/280 500/430/410/370/330/280/250
Dehumidifying Volume L/h 1.2 0.8
EER W/W 3.52 3.75
COP W/W 3.96 3.97
SEER W/W 7.0 7.2
SCOP(Average/Warmer/Colder) W/W 4.1/5.3/- 4.0/5.3/-
Application Area m
2
16-24 12-18
Indoor
Unit
Indoor Unit Model GEH12AA-K6DNA1A/I GEH09AA-K6DNA1F/I
Indoor Unit Product Code CV010N02900/CV010N02901 CV010N02700/CV010N02701
Fan Type Centrifugal Centrifugal
Fan Diameter Length(DXL) mm Φ370X80 Φ370X80
Cooling Speed
(SH/H/HM/M/LM/L/SL)
r/min 750/650/600/550/500/450/350 650/560/530/480/430 /370/320
Heating Speed
(SH/H/HM/M/LM/L/SL)
r/min 750/650/600/550/500/450/350 650/560/530/480/430/370/320
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.15 0.15
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 2-1.3 2-1.3
Evaporator Coil Length (LXDXW) mm 511X400X25.4 511X400X25.4
Swing Motor Model MP24EB/MP24AE MP24EB/MP24AE
Swing Motor Power Output W 1.5/1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level
(SS/H/MH/M/ML/L/SL)
dB (A)
Cooling:44/40/38/36/33/29/25
Heating:44/40/38/36/33/29/25
Cooling:39/36/33/31/29/26/23
Heating:38/36/32/30/28/25/22
Sound Power Level
(SS/H/MH/M/ML/L/SL)
dB (A)
Cooling:54/50/48/46/43/39/35
Heating:54/50/48/46/43/39/35
Cooling:50/48/45/44/42/38/34
Heating:50/48/45/44/42/38/34
Dimension (WXHXD) mm 700X215X600 700X215X600
Dimension of Carton Box (LXWXH) mm 785X280X682 785X280X682
Dimension of Package(LXWXH) mm 788X295X685 788X295X685
Net Weight kg 15.5 15.5
Gross Weight kg 18.5 18.5
2. Specications
2.1 Specication Sheet

Gree GEH09AA-K6DNA1F Specifications

General

Brand	Gree
Model	GEH09AA-K6DNA1F
Category	Air Conditioner
Language	English

Summary

Part I: Technical Information

1. Summary

2.1 Specification Sheet

Detailed technical specifications for indoor and outdoor units.

4. Refrigerant System Diagram

5.1 Wiring Diagram

Wiring diagrams for indoor and outdoor units, including component identification.

5.2 PCB Printed Diagram

Printed circuit board layouts for indoor and outdoor units with component labels.

6.1 Remote Controller Introduction

6.4 Brief Description of Modes and Functions

Explains the operation of different modes like Cooling, Drying, Heating, and AUTO.

Part II: Installation and Maintenance

7. Notes for Installation and Maintenance

Important safety precautions and guidelines for installation and maintenance.

8.1 Requirements for Electric Connection

Guidelines for safe and correct electrical connections.

8.2 Installation of Indoor Unit

Detailed steps and considerations for installing the indoor unit.

8.3 Outdoor Unit Installation

Steps for correctly installing the outdoor unit, including support and location.

8.4 Vacuum Pumping and Leak Detection

8.5 Check after Installation and Test Operation

9.1 Error Code List

9.2 Procedure of Troubleshooting

9.3 Maintenance Method for Normal Malfunction
