18
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXD-B222A030 QXD-B222A030
Compressor Oil 5GSD-TB /Equivalent 5GSD-TB /Equivalent
Compressor Type Rotary Rotary
L.R.A. A 26 26
Compressor RLA A 4.5 4.5
Compressor Power Input W 1000 1000
Overload Protector HPA-030 HPA-030
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm
Fan Motor Speed(H/M/L) rpm 1050/960/870 1050/960/870
Output of Fan Motor W 16 16
Fan Motor RLA A 0.3 0.3
Fan Motor Capacitor 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm
mm 3-1.3 3-1.3
Coil Length (LXDXW) mm 442X38.1X228.6 442X38.1X228.6
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm
mm 3-1.3,1-1.4 3-1.3,1-1.4
Coil Length (LXDXW) mm 572X22.8X304.8/468X11.4X266.7 592X34.2X304.8/475X11.4X266.7
Fan Motor Speed rpm 1040/850 1040/850
Output of Fan Motor W 50 50
Fan Motor RLA A 0.5 0.5
Fan Motor Capacitor 3.5 3.5
