63
Maintenance
Service Manual
Above data is subject to change without notice.
55 Electric Box Sub-Assy 01700700101 1
56 Electric Box Assy 100002063284 1
57 Filter Sub-assy 2 11126043 1
58 Evaporator Assy 011001060422 1
59 Left Side Plate 200085000002 1
60 Guide Louver 2 1051609801 4
61 Guide Louver 1 1051609901 1
62 Guide Blade Lever 2002350001101 1
63 Swing Lever 2000350002501 1
64 Air Louver 1 1051610001 1
65 Air Louver 2 1051610101 2
66 Air Louver 3 1051610201 2
67 Front Panel 200003000009 1
68 Decorative Strip 2300010007101 1
69 Front Panel Sub-Assy 209004000025 1
70 Capillary Sub-assy 030006060315 1
71 4-Way Valve Assy 030152060181 1
72 Magnet Coil 430004017 1
73 Supporting Strip 01796007 1
74 Detecting Plate / /
75 Power Cord 4002046423 1
76 Remote Controller 11122471 1
77 Tie-in 1 20010900023 1
78 Pipe 05236058 1
79 Rear Clip (upper) 26116132 1
80 Rear Clip (nether) 26116135 1
81 Adaptor sub-assy 26116155 1
