35
Installation of indoor unit
Step one: Install drainage hose and connection pipe
● When connecting pipeline and wires, please
remove top cover and left&right side plates.
top cover and then draw out the top cover (see fig A).
2.Before removing left &right side plates, please
1.Remove the fixing screws (three screws) on the
loose four screws under the top cover. Please
3. After loosing the screws, pull the upper part of left
4.When connecting pipes and wires, please use the equipped accessories.
5.Install the connection pipe at the right side of the unit body. Before installation,
please remove one screw used for fixing the cover plate of connection and then
6. By referring the relative position between wall hole and unit body, please select
left elbow pipe or right elbow pipe. (see fig E).
7. You can select to cut off the baiting of exit pipe hole according to the elbow pipe
direction, and then put the connection pipe through the exit pipe hoe and then
connect the connection pipe (see fig F and fig G).
you can remove the cover plate of connection pipe (see fig D).
and right side plates out-
wards by referring to fig C①
and lift the door plate up-
wards by referring fig C②,
and then left&right side
plates can be removed.
Fig A
Fig b①
Fig c
Fig b②
see the procedure as below:
(1)When the side plate is closed, loose #3 and #8
screws in the screw holes at both sides (see fig B①).
(2)Push left and right side plates to open status, and
then loosen #11 screw and #12 screw in the screw
holes. (see fig B②)
①
②
①
②
6
7
8
9
10
1
2
3
4
5
11
12
1
2
4
5
6
7
9
10
