Gree GVH24AK-K3DNC8A User Manual

Service Manual
2
Technical Information
2. Specications
2.1 Specication Sheet
Parameter Unit Value
Model GVH24AK-K3DNC8A
Product Code CH057000100
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50/60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 7100
Heating Capacity W 8800
Cooling Power Input W 2220
Heating Power Input W 2750
Cooling Power Current A 10.46
Heating Power Current A 13.03
Rated Input W 3800
Rated Cooling Current
A 21.00
Rated Heating Current A 22.00
Air Flow Volume(SH/H/M/L/SL) m
3
/h 1480/1200/1060/750/570
Dehumidifying Volume L/h 3.0
EER W/W 3.20
COP W/W 3.20
SEER W/W /
HSPF W/W /
Application Area m
2
46-70
Indoor Unit
Model of indoor unit GVH24AK-K3DNC8A/I
Product Code CH057N00100
Fan Type Centrifugal
Diameter Length(DXL) mm Φ111.5X1959
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1250/1020/900/780/480
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 1250/1020/900/780/480
Output of Fan Motor W 30
Fan Motor RLA A 0.12
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ5
Row-n Gap mm 2-1.3
Coil Length (LXDXW) mm 952X23X369
Swing Motor Model MP35GD/MP35GT/MP50AC
Output of Swing Motor W 2.5/2.5/3.5
Fuse A 5
Sound Pressure Level (SH/H/M/L/SL) dB (A) 47/42/39/35/30
Sound Power Level (SH/H/M/L/SL) dB (A) 61/56/53/49/44
Dimension (WXHXD) mm 458X1790X458
Dimension of Carton Box (LXWXH) mm 1940X555X575
Dimension of Package(LXWXH) mm 1943X558X590
Net Weight kg 50
Gross Weight kg 55

Gree GVH24AK-K3DNC8A Specifications

General

Brand	Gree
Model	GVH24AK-K3DNC8A
Category	Air Conditioner
Language	English
