Gree GVH24AK-K3DNC8A User Manual

Service Manual
5
Technical Information
2.4 Cooling Data Sheet in Rated Frequency
Instruction:
T1: Inlet and outlet pipe temperature of evaporator
T2: Inlet and outlet pipe temperature of condenser
P: Pressure at the side of big valve
Connection pipe length: 5 m.
Rated cooling
condition(°C) (DB/WB)
Model
Pressure of gas pipe
connecting indoor and
outdoor unit
Inlet and outlet pipe temperature
of heat exchanger
Fan speed of
indoor unit
Fan speed of
outdoor unit
Compressor
revolution
(rps)
Indoor Outdoor P (MPa) T1 (°C) T2 (°C)
27/19 35/24 24K 0.8 to 1.0
in:8~11
out:11~14
in:75~85
out:37~43
Super High High 89
Rated heating
condition(°C) (DB/WB)
Model
Pressure of gas pipe
connecting indoor and
outdoor unit
Inlet and outlet pipe temperature
of heat exchanger
Fan speed of
indoor unit
Fan speed of
outdoor unit
Compressor
revolution
(rps)
Indoor Outdoor P (MPa) T1 (°C) T2 (°C)
20/- 7/6 24K 2.5 to 2.7
in:75~85
out:37~43
in:1~3
out:3~5
Super High High 87
Cooling:
Heating:
2.5 Noise Curve
60
60
60 80
100
50
50
40
40
40
30
30
20
20
20
10
0
0
Noise/dB(A)
low low
Middle
High Super Super High
)A(Bd/esioN
Indoor side noise when blowing
Indoor fan motor rotating speed
Compressor frequency/Hz
Outdoor side noise when blowing

Gree GVH24AK-K3DNC8A Specifications

General

Brand	Gree
Model	GVH24AK-K3DNC8A
Category	Air Conditioner
Language	English
