GWC24QEXF-D3DNC4C/O
The component is only for rererence;please refer to the actual product
Some models may not contain some parts, please refer to the actual product.
NO. Description
1 Front Grill
2 Front Panel
3 Axial Flow Fan
4 Chassis Sub-assy
5 Compressor and Fittings
6 Capillary Sub-assy
7 Right Side Plate
8 Valve Support
9 Cut-off valve 1/4(N)
10 Cut-off valve 1/2(N)
11 Valve Cover
12 Cover of Pass Wire
13 Terminal Board
14 Suction Tube-Assy
1 2 3 4 5 6 7 8 9 10
12
13
14
16
17181920212223
24
25
26
27
11
28
15
NO. Description
15 Discharge Tube-Assy
16 Condenser Assy
17 Clapboard
18 Motor Support
19 Motor
20 Top Cover Assy
21 Left Side Plate
22 Condenser Left Border Plate
23 Electric Box Assy
24 Radiator
25 Electric Box
26 Main Board
27 Electric Box Cover
28 Rear Grill
