5HPRYDO3URFHGXUH
heat exchanger
thermistor
2
2
1
1
3
6. Remove vertical louver
Loosen the clasp connecting the vertical
louver and rear case assy.
clasp
Remove the vertical louver to the separate
louver with bottom assembly.
vertical louver
7. Remove electric box
Disconnect the indoor tube temperature sensor.
Remove the screws at the joint of the earthing
wire and evaporator.
screw
earthing wire
Loosen the clasp at the joint of the electric
box cover and the electric box.
Remove the electric box cover.
electric box cover
clasp
