5HPRYDO3URFHGXUH
8. Remove motor and motor suppor t
Remove the 4 tapping screws fixing the motor and
disconnect the leading wire insert of the motor. Then
remove the motor.
Remove the 2 tapping screws fixing the motor
support and lift the motor support to remove it .
9. Remove electric box
Remove screws fixing the electric box subassembly;
loosen the wire bundle and unplug the wiring
terminals. Then lift the electric box to remove it .
10. Remove isolation shee t
Remove the 3 screws fixing the isolation sheet and
then remove the isolation sheet.
11 . Remove soundproof sponge
Remove the soundproof sponge wrapping the
compressor.
isolation sheet
soundproof sponge
electric bo x
motor suppor t
moto r
