100
Installation and Maintenance
Service Manual
Steps
12.Remove gas valve and liquid valve
liquid valve
gas valve
Twist off the 2 bolts fixing the valve sub-assy.
Unsolder the soldering joint between gas valve
and air-return pipe and then remove the gas
valve.(note: when unsoldering the soldering joint,
wrap the gas valve with wet cloth completely to
avoid the damage to valve, and release all
refrigerant completely at first). Unsolder the
soldering joint between liquid valve and
connection pipe of liquid valve, and then remove
the liquid valve.
Twist off the screws connecting valve support and
chassis, and then remove the valve support.
14.Remove compressor
compressor
13.Remove valve support
valve support
Twist off the 3 foot nuts on compressor and then
remove the compressor.
Procedure
To Next Page
