Gree GWC30QF-D3DNB4G User Manual

39
Installation and Maintenance
Service Manual
8. Installation
8.1 Installation Dimension Diagram
Space to the ceiling
Space to the wall
At least 5 7/8 inch
At least 98 7/16 inch
At least 5 7/8 inch
At least 5 7/8 inch
Space to the wall
Space to the obstruction
roolf eht ot ecapS
Space to the obstruction
Drainage pipe
Space to the wall
Space to the obstruction
Space to the obstructio
Space to the obstruction
At least 19 11/16 inch
At least 11
7/8
inch
At least 19 11/16 inch
At least 11 7/8 inch
At least 78 3/4 inch
At least 118 inch

Gree GWC30QF-D3DNB4G Specifications

General

Brand	Gree
Model	GWC30QF-D3DNB4G
Category	Air Conditioner
Language	English
