86
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
VIRU36HP230V1AO
VIRU30HP230V1AO
Product Code CB432W10100 CB432W10000
1 Front Grill 01574106 01574106 1
2 Cabinet 01435007P 01435007P 1
3 Axial Flow Fan 10335014 10335014 1
4 Drainage hole Cap 76715005 76715005 1
5 Electrical Heater (Chassis) 7651000413 7651000413 1
6 Drainage Joint 26113009 26113009 1
7 Clapboard Sub-Assy 0124525304 0124525304 1
8 Magnet Valve Sub-assy 030025000055 030025060028 1
9 Magnet Valve Sub-assy 030025000056 030025060027 1
10 Inhalation Tube Sub-assy 030010000570 030010060043 1
11 Compressor and Fittings 00204100030 009001000013 1
12 Electrical Heater(Compressor) 7651873209 7651873209 1
13 Accumulator 07424100031 07424100031 1
14 Electronic Expansion Valve assy B 030174000139 030174060018 1
15 Right side plate 017038000055 017038000055 1
16 Valve Support Sub-Assy 01805200222P 01805200222P 1
17 Cut off Valve Sub-Assy 030057000153 030057000153 1
18 Valve Cover 22245005 22245005 1
19 Cut off Valve 07133157 07133157 1
20 Handle 2623305301 2623305301 1
21 Handle Assy 02113109 02113032P 1
22 Gas-liquid Separator 07223048 07223048 1
23 4-Way Valve Assy 030152000370 030152060015 1
24 Bafe Plate Sub-assy 01355200016P 01355200016P 1
25 Electronic Expansion Valve assy A 030174000138 030174000138 1
26 Temperature Sensor 3900007201 3900007201 1
27 Rear Grill 01475012 01475012 1
28 Condenser Assy 011002000628 011002060047 1
29 Top Cover 0125500901P 0125500901P 1
30 Motor Support Sub-Assy 017012000155 017012000155 1
31 Left Side Plate 01305064P 01305064P 1
32 Main Board 300027000042 300027000519 1
33 Electric Box Sub-Assy 017007000632 017007000632 1
34 Radiator 43003400001601 43003400001601 1
35 Terminal Board Support sub-assy 01715016 01715016 1
36 Terminal Board 420001000004 420001000004 1
37 Electric Box Assy 100002003294 100002004090 1
38 Brushless DC Motor 15010400000102 15010400000102 1
To Next Page
