Service Manual
Technical Information
Model
1.GWH09TB-S3DNA1D
2.GWH09TB-S3DNA2D
3.GWH09TB-S3DNA3D
GWH09TB-S3DNA1D
Product Code
1.CB148008400
2.CB411002902
3.CB412003300
CB148008401
CB148008407
Power Supply
Rated Voltage
V~
220-240 220-240
Rated Frequency
Hz
50/60 50/60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity
W
2600 2600
Heating Capacity
W
3000 3000
Cooling Power Input
W
600 600
Heating Power Input
W
650 650
Cooling Current Input
A
2.7 2.7
Heating Current Input
A
3.2 3.2
Rated Input
W
1600 1600
Rated Current
A
7.1 7.1
Air Flow Volume(SH/H/MH/M/ML/L/SL)
m
3
/h
650/600/550/500/450/400/350 650/600/550/500/450/400/350
Dehumidifying Volume
L/h
0.8 0.8
EER
W/W
4.33 4.33
COP
W/W
4.62 4.62
SEER 8.5 8.5
HSPF / /
Application Area
m
2
12-18 12-18
Indoor Unit
Indoor Unit Model
1.GWH09TB-S3DNA1D/I
2.GWH09TB-S3DNA2D/I
3.GWH09TB-S3DNA3D/I
GWH09TB-S3DNA1D/I
Indoor Unit Product Code
1.CB148N08400
2.CB411N02902
3.CB412N03300
CB148N08400
CB148N08402
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL)
mm
Φ98X662 Φ98X662
Cooling Speed(SH/H/MH/M/ML/L/SL)
r/min
1300/1050/1000/900/800/700/500 1300/1050/1000/900/800/700/500
Heating Speed(SH/H/MH/M/ML/L/SL)
r/min
1300/1150/1080/1030/980/900/850 1300/1150/1080/1030/980/900/850
Fan Motor Power Output
W
15 15
Fan Motor RLA
A
0.07 0.07
Fan Motor Capacitor
μF
/ /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter
mm
Φ7 Φ7
Evaporator Row-n Gap
mm
2-1.5 2-1.5
Evaporator Coil Length (LXDXW)
mm
662X25.4X305 662X25.4X305
Swing Motor Model MP24HA/MP24HB/MP24HC MP24HA/MP24HB/MP24HC
Swing Motor Power Output
W
2 2
Fuse Current
A
3.15 3.15
Sound Pressure Level
(SH/H/MH/M/ML/L/SL)
dB (A)
43/36/34/32/30/28/26 43/36/34/32/30/28/26
Sound Power Level
(SH/H/MH/M/ML/L/SL)
dB (A)
55/48/46/44/42/40/38 55/48/46/44/42/40/38
Dimension (WXHXD)
mm
866X292X209 866X292X209
Dimension of Carton Box (LXWXH)
mm
942X374X282 942X374X282
Dimension of Package (LXWXH)
mm
945X377X297 945X377X297
Net Weight
kg
11 11
Gross Weight
kg
13 13
2. Specications
2.1 Specication Sheet
