Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model
1.GWH09AAA-K3NNA2A
2.GWH09AAA-K3NNA1A
3.GWH09AAA-K3NNA3A
1.GWH12AAB-K3NNA2A 2.GWH12AAB-K3NNA1A
3.GWH12AAB-K3NNA3A 4.GWH12AAB-K3NNA4A
5.GWH12AAB-K3NNA5A
Product Code
1.CA115016500/
CA115016501
2.CA115014400/
CA115014401
3.CA478000700
1.CA115014100/CA115014101
2.CA476003000/CA476003001
3.CA478000600 4.CA479002300
5.CA488001900/CA488001901
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity W 2550 3250
Heating Capacity W 2650 3400
Cooling Power Input W 794 1012
Heating Power Input W 734 941
Cooling Power Current A 3.7 4.32
Heating Power Current A 3.3 4.40
Rated Input W 1120 1230
Rated Current A 6.2 6.3
Air Flow Volume(SH/H/M/L/SL) m
3
/h 470/420/370/250/- 550/500/430/330/-
Dehumidifying Volume L/h 0.8 1.2
EER W/W 3.21 3.21
COP W/W 3.61 3.61
SEER W/W / /
HSPF W/W / /
Application Area m
2
12-18 15-22
Indoor Unit
Model of Indoor Unit
1.GWH09AAA-K3NNA2A/I
2.GWH09AAA-K3NNA1A/I
3.GWH09AAA-K3NNA3A/I
1.GWH12AAB-K3NNA2A/I 2.GWH12AAB-K3NNA1A/I
3.GWH12AAB-K3NNA3A/I 4.GWH12AAB-K3NNA4A/I
5.GWH12AAB-K3NNA5A/I
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ92X505 Φ93X580
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1300/1200/1100/850/- 1350/1200/1100/850/-
Fan Motor Heating Speed(SH/H/M/L/
SL)
r/min 1200/1100/1000/900/- 1350/1200/1100/900/-
Output of Fan Motor W 10 20
Fan Motor RLA A 0.15 0.215
Fan Motor Capacitor μF 1 1
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7.94 Φ7.94
Row-n Gap mm 1-1.2 1-1.2
Coil Length (LXDXW) mm 508X19.05X254 583X19.05X264
Swing Motor Model MP24AN MP24AN
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/M/L/SL)
dB
(A)
40/38/35/26/- 42/39/36/33/-
Sound Power Level (SH/H/M/L/SL)
dB
(A)
50/48/45/36/- 52/49/46/43/-
Dimension (WXHXD) mm 698X250X185 773X250X185
Dimension of Carton Box (LXWXH) mm 742X306X244 817X306X244
Dimension of Package (LXWXH) mm 747X322X255 822X322X255
Net Weight kg 7.5 8.5
Gross Weight kg 8.5 9.5
