Gree GWH12AAB-K3NNA1A User Manual

75
Installation and Maintenance
Service Manual
4. Remove front grille
Remove connection screws between the front
grille and the front panel. Then remove the front
grille .
Remove connection screws connecting the front
panel with the chassis and the motor support,
and then remove the front panel.
Remove connection screws connecting th e
right side plate with the chassis, the valv e
support and the electric box. Then remove
the right side plate.
Remove the nut on the blade and then remove
the axial flow blade.
5. Remove front panel
front grille
6. Remove right side plat e
front pa ne l
right side plate
7. Remove axial flow blad e
axial flow blad e
ProcedureSteps
