Technical Information
Service Manual
Model
1.GWH12QB-K6DNB8I 2.GWH12QB-K6DNB2I
3.GWH12QB-K6DNB4I 4.GWH12QB-K6DNA1I
5.GWH12QB-K6DND6I 6.GWH12QB-K6DNA5I
7.GWH12QB-K6DND6I 8.GWH12QB-K6DNA3I
9. GWH12QB-K6DNC6I 10.GWH12QB-K6DNC4I
11.GWH12QB-K6DNC8I 12.GWH12QB-K6DNB8I
Product Code
1.CB438006800/CB438006801 2.CB432012300
3.CB434010600/CB434010601 4.CB419015000
5.CB460005100 6.CB425011800 7.CB460005101
8.CB424006500 9CB443005400 10.CB444007501
11.CB456006200 12.CB438006802
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 3200
Heating Capacity W 3500
Cooling Power Input W 997
Heating Power Input W 970
Cooling Current Input A 4.42
Heating Current Input A 4.30
Rated Input W 1500
Rated Current A 6.21
Air Flow Volume(SH/H/M/L/SL) m
3
/h 560/480/410/290/-
Dehumidifying Volume L/h 1.4
EER W/W 3.21
COP W/W 3.61
SEER 6.10
SCOP(Average/Warmer/Colder) 4.00
HSPF /
Application Area m
2
15-22
Indoor
Unit
Indoor Unit Model
1.GWH12QB-K6DNB8I/I 2.GWH12QB-K6DNB2I/I
3.GWH12QB-K6DNB4I/I 4.GWH12QB-K6DNA1I/I
5.GWH12QB-K6DND6I/I 6.GWH12QB-K6DNA5I/I
7.GWH12QB-K6DND6I/I 8.GWH12QB-K6DNA3I/I
9.GWH12QB-K6DNC6I/I 10.GWH12QB-K6DNC4I/I
11.GWH12QB-K6DNC8I 12.GWH12QB-K6DNB8I/I
Indoor Unit Product Code
1.CB438N06800/CB438N06801 2.CB432N12300
3.CB434N10600/CB434N10601 4.CB419N15000
5.CB460N05100 6.CB425N11800 7.CB460N05101
8.CB424N06500 9.CB443N05400 10.CB444N07501
11.CB456N06200 12.CB438N06802
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф98X580
Cooling Speed(SH/H/M/L/SL) r/min 1350/1200/1050/750/-
Heating Speed(SH/H/M/L/SL) r/min 1350/1200/1050/850/-
Fan Motor Power Output W 20
Fan Motor RLA A 0.215
Fan Motor Capacitor μF 1
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length(LXDXW) mm 584X22.8X266.7
Swing Motor Model MP24AA
Swing Motor Power Output W 1.5
Fuse Current A 3.15
Sound Pressure Level(SH/H/M/L/SL)dB (A) 41/37/33/25/-
Sound Power Level(SH/H/M/L/SL) dB (A) 55/47/43/35/-
Dimension(WXHXD) mm 790X275X200
Dimension of Carton Box(LXWXH) mm 863X268X352
Dimension of Package(LXWXH) mm 866X271X367
Net Weight kg 9
Gross Weight kg 11
2. Specications
2.1 Specication Sheet
