73
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyGWH12QB-K6DNB8I/I GWH12QB-K6DNB2I/I GWH12QB-K6DNB4I/I
Product Code CB438N06800 CB432N12300 CB434N10600
1 Front Panel 20000300073T 20000300019S 20000300026T 1
2 Filter Sub-Assy 11122219 11122219 11122219 2
3 Display Board 30565260 30565260 30565260 1
4 Front Case Assy 00000200040 00000200040 00000200040 1
5 Guide Louver 1051276301 1051276301 1051276301 1
6 Helicoid Tongue 26112508 26112508 26112508 1
7 Left Axile Bush 10512037 10512037 10512037 1
8 Rear Case assy 20162010 20162010 20162010 1
9 Drainage Hose 0523001408 0523001408 0523001408 1
10 Ring of Bearing 26152022 26152022 26152022 1
11 O-Gasket sub-assy of Bearing 7651205102 7651205102 7651205102 1
12 Evaporator Supper 2 24212180 24212180 24212180 1
13 Cold Plasma Generator 1114001603 1114001603 1114001603 1
14 Evaporator Assy 0110010009507 0110010009507 0110010009507 1
15 Wall Mounting Frame 01252043 01252043 01252043 1
16 Cross Flow Fan 10352059 10352059 10352059 1
17 Fan Motor 150120874 150120874 150120874 1
18 Connecting pipe clamp 2611216401 2611216401 2611216401 1
19 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
20 Stepping Motor 1521212901 1521212901 1521212901 1
21 Crank 73012005 73012005 73012005 1
22 Electric Box Assy 100002002895 100002002895 100002002895 1
23 Axile Bush 10542036 10542036 10542036 1
24 Terminal Board 42011233 42011233 42011233 1
25 Jumper 4202021911 4202021911 4202021911 1
26 Main Board 30145096 30145096 30145096 1
27 Screw Cover 2425203001 2425203001 2425203001 1
28 Electric Box Cover Sub-Assy 0140206501 0140206501 0140206501 1
29 Shield Cover of Electric Box Cover 01592150 01592150 01592150 1
30 Electric Box Cover 20112207 20112207 20112207 1
31 Connecting Cable / / / /
32 Connecting Cable 4002052317 4002052317 4002052317 0
33 Remote Controller 305001000087 305001000087 305001000087 1
34 Detecting Plate 30110154 30110154 30110154 1
To Next Page
