Technical Information
Service Manual
2. Specications
Model GWHD(14)NK3DO(LCLH) GWHD(14)NK3DO
Product Code CB228W06500 CB228W06501
Power
supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling capacity(max~min) W 4100(2052~4396) 4100(2052~4396)
Heating capacity(max~min) W 4400(2491~5422) 4400(2491~5422)
Cooling Power Input(max~min) W 1200 1200
Heating Power Input(max~min) W 1180 1180
Cooling Current Input A 5.32 5.32
Heating Current Input A 5.10 5.10
Rated Power Input W 1780 1780
Rated Current A 7.90 7.90
SEER W/W 6.10 6.10
SCOP W/W 4.00 4.00
Outdoor
Unit
Compressor Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model QXA-B141zF030A QXA-B141zF030A
Compressor Refrigerant Oil Type RB68EP RB68EP
Compressor Type Inverter Rotary Inverter Rotary
L.R.A A 25 25
Compressor Rated Load Amp (RLA) A 7.2 7.2
Compressor Power Input W 1440 1440
Compressor Thermal Protector
"1NT11L-6233
KSD115
O
CHPC115/95U1"
"1NT11L-6233
KSD115
O
CHPC115/95U1"
Throttling Method Electron expansion valve Electron expansion valve
Cooling Operation Ambient Temperature Range
O
C -15~43 18~43
Heating Operation Ambient Temperature Range
O
C -20~24 -15~24
Condenser Material Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ9.52 Φ9.52
Rows-Fin Gap(mm) mm 2-1.4 2-1.4
Coil length (l) X height (H) X coil width (L) mm 800X44X559 800X44X559
Fan Motor Speed (rpm) (H/M/L) rpm 900 900
Output of Fan Motor W 30 30
Fan Motor RLA A / /
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit m
3
/h 2600 2600
Fan Type-Piece Axial-ow Axial-ow
Fan Diameter mm Φ438-116 Φ438-116
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Dimension (W/H/D) mm 903X596X378 903X596X378
Dimension of Package (L/W/H) mm 945X417X630 945X417X630
Dimension of Package(L/W/H) mm 948X420X645 948X420X645
Net Weight kg 43 43
Gross Weight kg 46 46
efrigerant Charge R410A R410A
Refrigerant Charge kg 1.40 1.40
