Gree GWHD(14)NK3DO User Manual

5
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor
Unit
Cross-sectional Area of Power Cable Conductor mm
2
/ /
Recommended Power Cable(Core) N 3 3
Connection Pipe Connection Method - Flare Connection Flare Connection
Not Additional Gas Connection Pipe Length m 10 10
Connection Pipe Gas Additional Charge g/m 20 20
Outer Diameter of Liquid Pipe(GREE Allocation)
(Metric)
mm Φ6 Φ6
Outer Diameter of Gas Pipe(GREE Allocation)
(Metric)
mm Φ9.52 Φ9.52
Outer Diameter of Liquid Pipe(GREE Allocation)
(Metric)
mm Φ6 Φ6
Outer Diameter of Gas Pipe(GREE Allocation)
(Metric)
mm Φ9.52 Φ9.52
Connection Pipe Max. Height Distance(indoor and
indoor)
m 5 5
Max. equivalent connection pipe length(outdoor to
last indoor)
m 10 10
Connection Pipe Max. Length Distance(total lenght) m 20 20

Gree GWHD(14)NK3DO Specifications

General

Brand	Gree
Model	GWHD(14)NK3DO
Category	Air Conditioner
Language	English
