Installation location selection
Indoor unit
Outdoor unit
NOTE:
Install in the following place may cause malfunction. If it is unavoidable, contact with service center please.
Place where oil(machine oil) is used.
The place where a lot of salinities such as coast exists.
Place where a sulfured gas such as the hot spring zones is generated.
Place where high-frequency waves are generated by radio equipment, welders and medical
equipment.
Other place with special circumstance.
The inlet and outlet should be far from the obstructions so that the outflow air can reach all parts of the room;ｏｆ
A location from which the condensation water can be drained out conveniently;
A location easily connect with the outdoor unit;
Avoid a location where there is heat source, steam and inflammable gas;
Install in a location where is strong enough to withstand the full weight and vibration of the unit.and will
not increase the operation noise.
Be sure that the installation conforms to the installation dimension diagram.
Be sure to leave enough space to allow access for routine maintenance. The height of the indoor unit
location should be more than 230cm from the floor.
Install in a location where is 1m or more away from other electric appliances such as television, audio devices, etc.
Do not use the unit in the immediate surroundings of a laundry, a bath, a shower or a swimming pool.
Select location where is easy to remove and clean the filter.
Select location from which noise and outflow air emitted by unit will not disturb neighbors.
Select location where ventilate freely.
The inlet and outlet should not be covered.
The location should be able to withstand the full weight and vibration of the outdoor unit.
There should be no danger of flammable gas or corrosive gas leaks.
Be sure that the installation conforms to the installation dimension diagram.
