Air to Water Heat Pump
Service Manual- Versati Series
NBJOUFOBODF
Ɣ
Parts List of GRS-CQ16Pd/Na-H(I) for ER010N1090
No. Name of part Part code Quantity
1 Front Panel Cover 01262866P 1
2 Front Panel 01542808 1
3 Display Board 30293301 1
4 Outlet Water Pipe Sub-Assy 04262800007 1
5 Water Flow Switch Sub-Assy 45028062 1
6 Outlet Water Pipe Sub-Assy 04262800005 1
7 Water Pressure Gauge 49028009 1
8 Strainer 07412808 1
9 Bottom Cover Plate 01262876 1
10 L-shaped Pipe 05022909 1
11 Expansion Drum 07422804 1
12 Plate-type Heat Exchanger 00902812 1
13 Chassis Sub-Assy 01192819P 1
14 Electric Box Assy 01392800016 1
15 Terminal Board 42011051 1
16 Terminal Board 420102511 1
17 Thermostat 45048006 1
18 Terminal Board 42010249 1
19 Main Board 30223311 1
20 Transformer 43110270 1
21 AC Contactor 44010232 2
22 Electric Box Cover 01422821 1
23 Connection Pipe Sub-Assy 05032851 1
24 Electric Heater 32000004 1
25 Entering Water Pipe Sub-Assy 04362925 1
26 Top cover 01262875 1
27 Auto Air Outlet Valve 07108208 1
28 Relief Valve 07382814 1
29 Receiver Board 30261014 1
30 Sensor Sub-Assy 39008051G 1
31 Temperature Sensor 39000283G 1
