148
Air to Water Heat Pump
Service Manual- Versati Series
NBJOUFOBODF
Ɣ
Parts List of SXVD200LCJ/A-K for ER20000160
No. Name of part Part code Quantity
1 Bottom Cover Plate 01262801P 1
2 Fixation Bracket (Outside) 01802819P 1
3 Body Of Outdoor Unit 0151283301P 1
4 Electric Box Assy 01392865 1
5 Bottom Cover Plate 01262806P 1
6 Drainage Pipe Sub-Assy 04362821 1
7 Water Tank Base 01892825 3
8 Water Pipe Joint (accessory) 06652838 1
9 Electric Heater 32110008 1
10 Thermostat 45048005 1
11 Drainage hose 05230012 1
12 Electric Box Cover 26902805 1
13 Gasket 75042802 1
14 Thermostat 45048003 1
15 Relief Valve 07382801 1
16 Cable Cross Loop 765100267 2
17 Toggle Switch Sheath 26902823 1
18 Gasket 7041280401 1
19 Magnesium Sub-Assy 04162801 1
20 Toggle Switch Sheath 2690282301 1
21 Temperature Sensor 3900028302 1
22 Gasket 70412804 2
23 Temp Sensor Pipe Sub-Assy 04162802 2
24 Toggle Switch Sheath 26242801 2
Ɣ
Parts List of SXVD200LCJ/A-M for ER20000240
No. Name of part Part code Quantity
1 Bottom Cover Plate 01262801P 1
2 Fixation Bracket (Outside) 01802819P 1
3 Body Of Outdoor Unit 0151283301P 1
4 Electric Box Assy 01392885 1
5 Bottom Cover Plate 01262806P 1
6 Drainage Pipe Sub-Assy 04362821 1
7 Water Tank Base 01892825 3
8 Water Pipe Joint (accessory) 06652838 1
9 Electric Heater 32110009 1
10 Thermostat 45048016 1
11 Drainage hose 05230012 1
12 Electric Box Cover 26902805 1
13 Gasket 75042802 1
14 Thermostat 45048003 1
15 Relief Valve 07382801 1
16 Cable Cross Loop 765100267 2
17 Toggle Switch Sheath 26902823 1
18 Gasket 7041280401 1
19 Magnesium Sub-Assy 04162801 1
20 Toggle Switch Sheath 2690282301 1
21 Temperature Sensor 3900028302 1
22 Gasket 70412804 2
23 Temp Sensor Pipe Sub-Assy 04162802 2
24 Toggle Switch Sheath 26242801 2
