Air to Water Heat Pump
Service Manual- Versati Series
QSPEVDU
AIR TO WATER HEAT PUMP
Model
GRS-CQ16Pd/
Na-K(O)
GRS-CQ12Pd/
Na-M(O)
GRS-CQ14Pd/
Na-M(O)
GRS-CQ16Pd/
Na-M(O)
GRS-CQ16Pd/
Na-H(O)
Product Code ER010W1010 ER010W1060 ER010W1070 ER010W1080 ER010W1090
Power Supply
V,Ph,Hz 220-240V,~,50Hz 380-415V,3N~,50Hz 380V,3N~,60Hz
Capacity
1
+HDWLQJÀRRU
heating)
kW 16 12 14 15 15
&RROLQJÀRRUFRROLQJ kW 15.5 14 15 15.5 15.5
Power
Input
1
+HDWLQJÀRRU
heating)
kW 3.95 2.67 3.33 3.7 3.7
&RROLQJÀRRUFRROLQJ kW 4.63 3.68 4.29 4.43 4.43
Capacity
2
Heating(Fan coil or
Radiator)
kW 14 11 12 14 14
Cooling(for Fan coil) kW 11.5 10 10.5 11 11
Power
Input
2
Heating(Fan coil or
Radiator)
kW 4.59 3.24 3.58 4.38 4.38
Cooling(for Fan coil) kW 4.6 3.45 3.75 4.07 4.07
Refrigerant
Type - R410A R410A R410A R410A R410A
Charge g 3300 3500 3500 3500 3500
Sanitary water Temperature
40~80 40~80 40~80 40~80 40~80
Sound Pressure Level dB(A) 62 59 59 62 62
Gas Piping Connection mm 15.9 15.9 15.9 15.9 15.9
Liquid Piping Connection mm 9.52 9.52 9.52 9.52 9.52
Outline Dimensions (W×D×H) mm 950×412×1253 950×412×1253 950×412×1253 950×412×1253 950×412×1253
Net Weight kg 99 99 99 99 99
Notes:
1
Capacities and power inputs are based on the following conditions:
a. Cooling conditions
Indoor Water Temperature 23°C/18°C;
Outdoor Air Temperature 35°CDB/24°CWB
b. Heating conditions
Indoor Water Temperature 30°C/35°C;
Outdoor Air Temperature 7°CDB/6°CWB
c. Standard piping length 7.5m
2
Capacities and power inputs are based on the following conditions:
a. Cooling conditions
Indoor Water Temperature 12°C/7°C;
Outdoor Air Temperature 35°CDB/24°CWB
b. Heating conditions
Indoor Water Temperature 40°C/45°C;
Outdoor Air Temperature 7°CDB/6°CWB
c. Standard piping length 7.5m

Gree VERSATI SERIES Specifications

General

Refrigerant	R410A
Type	Air to Water
Power Supply	220-240V, 50Hz
Heating Capacity Range	4kW - 16kW
Water Outlet Temperature (Heating)	55°C
Application	Underfloor heating, radiators, fan coils
Operating Temperature Range (Cooling)	10°C to 46°C
Noise Level	45-55 dB(A)
