Grohe Grohsafe User Manual

5
Index
Spare Parts
Table Of Contents . . . . . . . . . . . . . . . . . 1
Installation Dimensions . . . . . . . . . . . . 2
Spare Parts Drawing. . . . . . . . . . . . 3 + 4
Spare Parts List . . . . . . . . . . . . . . . . . . 5
Technical Data. . . . . . . . . . . . . . . . . . . . 6
Installation. . . . . . . . . . . . . . . . . . . . . . . 7
Rough Installation . . . . . . . . . . . . . . . . 7
Preassemble Valve . . . . . . . . . . . . . . . 8
Wall Plate Installation. . . . . . . . . . . . . 10
Bottom Outlet Installation. . . . . . . . . . 11
Reversed Supplies Installation. . . . . . 12
Maximum Hot Water Limit Setting . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . 14
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Trouble Shooting . . . . . . . . . . . . . . . . 15
Guarantee . . . . . . . . . . . . . . . . . . . . . . 19
Dear Customer,
Thank you for choosing a GROHE product.
Please follow these instructions carefully
and you will enjoy many years of reliable
service from this fitting.
No. Description Cat.-No.
Pack-
ing
unit
9 Handshower 28 216 1
9.1 Shower spray plate 45 794 1
10 Shower rail 28 666 1
10.1 Sliding shower holder 07 659 1
10.2 Shower rail holder 45 362 1
10.2.1 Cover cap 45 363 1
11 Flexible hose 28 151 1
12 Elbow outlet 28 680 1
12.1 Non-return valve 45 481 1
12.2 Cover cap 45 364 1
Optional accessories
13 Extension 25mm 47 069 1
14 Compensation ring 45 406 1
15 Service stops 47 038 2
No. Description Cat.-No.
Pack-
ing
unit
1 Handle complete 47 547 1
1.1 Screw and cap 47 548 1
2 Wall plate complete 47 549 1
2.1 Screws and stop 47 550 1
3 Pressure balancing 47 080 1
cartridge
4 Seal kit 47 552 1
5 Fixing set 47 553 1
6 Clips and screws 47 560 2
7 Shower arm 28 541 1
7.1 Rosette 02 201 1
8 Headshower 28 270 1
8.1 Filter 07 002 2
8.2 Shower spray plate 45 663 1
950632.book : i95063gb.fm Seite 5 Mittwoch, Oktober 4, 2000 7:42 AM
