Grundfos MS6000 Service Instructions

English (GB)
18
2. Winding resistances
2.1 MS6000T40
Voltage
Output power Winding resistance
[kW] [hp]
Between two phases [Ω]
DOL
Across one phase [Ω]
SD
3 x 220-230 V, 50 Hz
5.5 - 0.760 1.14
7.5 - 0.560 0.840
9.2 - 0.445 0.670
11 - 0.345 0.520
13 - 0.315 0.470
15 - 0.255 0.380
18.5 - 0.208 0.310
22 - 0.166 0.248
26 - - 0.212
30 - - 0.174
3 x 340-380 V, 50 Hz
5.5 - 1.86 -
7.5 - 1.54 -
9.2 - 1.28 -
11 - 1.03 -
13 - 0.825 -
15 - 0.695 -
18.5 - 0.555 -
22 - 0.425 -
26 - 0.415 -
30 - 0.315 -
3 x 380-400-415 V, 50 Hz
5.5 - 2.46 3.70
7.5 - 1.84 2.75
9.2 - 1.48 2.22
11 - 1.18 1.76
13 - 1.00 1.50
15 - 0.815 1.22
18.5 - 0.645 0.970
22 - 0.565 0.850
26 - 0.465 0.695
30 - 0.385 0.575
3 x 500-525 V, 50 Hz
5.5 - 3.86 -
7.5 - 3.00 -
9.2 - 2.30 -
11 - 1.86 -
13 - 1.50 -
15 - 1.26 -
18.5 - 1.02 -
22 - 0.880 -
26 - 0.735 -
30 - 0.615 -
3 x 208-220-230 V, 60 Hz
5.5 7,5 0.615 0.925
7.5 10 0.465 0.695
9.2 12 0.370 0.555
11 15 0.285 0.430
13 18 0.250 0.375
15 20 0.208 0.310
18.5 25 0.168 0.250
22 30 0.136 0.202
26 35 - 0.172
30 40 - 0.136
