– 7 –
System Pressures
Technicians with R-22 experience will need to become familiar working with high and
low side pressures that are much higher when using R-410A. A typical R-22 system
operates normally with a high side pressure of approximately 260 psi @ 120°F
condensing temperature and a low side pressure of approximately76 psi @ 45°F
evaporator saturation temperature.
A normally operating R-410A system with the same condensing temperature of
120°F and 45°F evaporator saturation temperature will have a high side pressure of
approximately 500 psi and a low side pressure of approximately 150 psi.
• 5/16-in. socket or drive
• 1/4-in. socket or drive: Ground screws and control assembly use 1/4-in. machine thread screws
• 3/8-in. socket or drive: For outdoor fan blade removal
• 4-mm Allen wrench: For indoor fan blade removal
• Volt Ohm Meter
• Amp probe
• Needlepoint meter leads
• Sealed system and R-410A recovery equipment
• Thermal paste (Part #: WX5X8927)
• Extension needed for condenser shroud screws
Tools Required
Caution
